48 mm x 48 mm x 65 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Output Time-limit contact: SPDT, Screw terminal, Memory backup, Key protect Switch
Model NumberDescription
H5CX-A-N48 mm x 48 mm x 84 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), Output Time-limit contact: SPDT, Screw terminal, Memory backup, Key protect Switch
H5CX-A11-N48 mm x 48 mm x 69.7 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), Output Time-limit contact: SPDT, 11-pin round socket, Memory backup, Key protect Switch
H5CX-A11D-N48 mm x 48 mm x 69.7 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Output Time-limit contact: SPDT, 11-pin round socket, Memory backup, Key protect Switch
H5CX-A11S-N48 mm x 48 mm x 69.7 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), 11-pin round socket, Memory backup, Key protect Switch
H5CX-A11SD-N48 mm x 48 mm x 69.7 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), 11-pin round socket, Memory backup, Key protect Switch
H5CX-AD-N48 mm x 48 mm x 65 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Output Time-limit contact: SPDT, Screw terminal, Memory backup, Key protect Switch
H5CX-AS-N48 mm x 48 mm x 84 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), Screw terminal, Memory backup, Key protect Switch
H5CX-ASD-N48 mm x 48 mm x 65 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Screw terminal, Memory backup, Key protect Switch
H5CX-BWSD-N48 mm x 48 mm x 65 mm, 12 to 24 VDC, Time range (4 range), Screw terminal, Memory backup, Key protect Switch
H5CX-L8-N48 mm x 48 mm x 69.7 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), Output Time-limit contact: SPDT, 8-pin round socket, Memory backup, Key protect Switch
H5CX-L8D-N48 mm x 48 mm x 69.7 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Output Time-limit contact: SPDT, 8-pin round socket, Memory backup, Key protect Switch
H5CX-L8E-N48 mm x 48 mm x 69.7 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), Output Time-limit contact: SPDT, Instantaneous contact: SPDT, 8-pin round socket, Memory backup, Key protect Switch
H5CX-L8ED-N48 mm x 48 mm x 69.7 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), Output Time-limit contact: SPDT, Instantaneous contact: SPDT, 8-pin round socket, Memory backup, Key protect Switch
H5CX-L8S-N48 mm x 48 mm x 69.7 mm, 100 to 240 VAC (50/60 Hz), Time range (10 range), 8-pin round socket, Memory backup, Key protect Switch
H5CX-L8SD-N48 mm x 48 mm x 69.7 mm, 24 VAC (50/60 Hz), 12 to 24 VDC, Time range (10 range), 8-pin round socket, Memory backup, Key protect Switch
